Practice Exercise F-1.2.2-xy

Plane Stress State: Determine the Magnitude and Direction of the Principal Stresses

Problem Statement

In a sheet, the stresses $\sigma_x = 20\mathrm{~MPa}$, $\sigma_y = 30\mathrm{~MPa}$ and $\tau_{xy} = 10\mathrm{~MPa}$ are given.

This illustration depicts a square sheet of metal. It lies with two sides in an x, y-coordinate system with the origin at the bottom-left corner of the sheet. The x-axis is positive to the right, and the y-axis is positive upward. Normal and shear stresses are represented for each side of the sheet, with arrows indicating their respective directions. — Fig. 1: Sheet with given stresses

Determine the magnitude and direction of the principal stresses.

Short Solution

Determine the Magnitude and Direction of the Principal Stresses.

$$ \begin{aligned} \sigma_{1} &= 36,180\mathrm{~MPa}~(\nearrow)\\ \varphi_1^* &= 58,283°\\ \sigma_{2} &= 13,820\mathrm{~MPa}~(\searrow)\\ \varphi_2^* &=-31,717° \end{aligned} $$

Comprehensive Solution

For the given $x$, $y$-coordinate system describing a plane where the x-axis points to the right in the positive direction and the y-axis points upward in the positive direction, and the given stresses $\sigma_x$, $\sigma_y$, and $\tau_{xy}$, we can use formula 1.10_xy to determine the principal stresses:
